1.2343 H11 SKD6 X37CrMoV5-1 Hot Work Tool Steel
Main Product: H11 1.2343 SKD6 Flat Bar / Round Bar
| 1.2343 H11 SKD6 X37CrMoV5-1 Supply Situation | ||
| Flat Bar | Round Bar | |
| Thickness/ Dia | 8 – 500mm | 8 – 1000mm |
| Surface | Black Surface / Milling or Machined Surface | Black Surface / Turned Surface / Peel Surface |
| Delivery Condition | Hot Rolled / Hot Forged ; EAF/ ESR ; Annealed | Hot Rolled / Hot Forged ; EAF/ ESR ; Annealed |
Products
Related Products
h13-1-2344-skd61-4cr5mosiv1
1.2343 H11 Hot Work Die Steel Plates / Round Bar
The steel grade 1.2343 is a chromium-molybdenum-vanadium alloyed tool steel, it is belong to the hot work die steel.
1.2343 H11 with good mechanical strength at high temperature, good toughness and ductility, as well as high tempering resistance combined with good machinability and polishability, Because of these properties, the 1.2343 widely used for die casting realm, extrusion industry and forging application.
1.2343 H11 International Standard:
1.2343 H11 Chemical Composition (%)
| C | Si | Mn | P | S | Cr | Mo | V |
| 0.33-0.43 | 0.80-1.25 | 0.20-0.60 | ≤0.03 | ≤0.03 | 4.75-5.50 | 1.10-1.60 | 0.30-0.60 |
1.2343 H11 Available Size
| Flat Bar Size(mm) | Round Bar Size(mm) | |||
| Thickness | Width | Length | Diameter | Length |
| 8-500 | 210-610 | 2000-5800 | 8-1000 | 2000-5800 |
1.2343 H11 Delivery Condition
Black Surface / Milling Surface / Turning Surface/ Peel surface
Hot Rolled / Forged ；EAF / ESR ; Annealed
1.2343 H11 Delivery Time
The stock 1.2343 sizes will be delivered within 15 days.
The customized, will be about 30-35 days.
